FACILITIES AND MACHINERY FOR
LARGE DIMENSION
COMPONENTS
FACILITIES
In Gometegui Industrial we have 4 workshops that suppose more than 10,000 m2 of covered work surface.
All workshops are equipped with cranes with lifting capacity up to 200 tons and cutting-edge machinery for performing the required work.
Our workshop is distributed by different areas that are designated according to the component to be manufactured and the works to carry out, always operating under the philosophy of Lean Manufacturing.
OXY-FUEL CUTTING OF STEEL PLATE
| SPECIFICATIONS | OXICUTTING | PLASMA |
| Maximum size: | 300 mm. | 400 mm. |
More options with our network of collaborators
PLATE ROLLER
| SPECIFICATIONS | |
| Thickness | 50- 75 mm |
| Ø minimum | 500 mm. |
| maximum width | 3 m. |
- More options with our network of collaborators
WELDING EQUIPMENT
|
MIG/MAG |
+ 30 semi-automatic up to 650 A |
|
SAW |
3 submerged arc carts |
|
SAW columns |
2 submerged arc columns + tandem |
|
SMAW |
5 |
|
TIG |
8 |
|
Positioner |
Up to 80 Tn in horizontal and 60 Tn in vertical |
|
Turning gear |
3 |
|
Arc-air machines |
5 |
HEAT TREATMENT
|
Width x height x length |
8.100×3.800×14.000 mm, |
|
Maximum temperature |
900ºC |
HORIZONTAL LATHE
|
|
UNIT 1 |
UNIT 2 |
|
Ø Max. |
2.400 mm |
880 mm |
|
Maximum length |
10.000 mm |
4.000 mm |
|
Maximum weight |
30 Tn |
– |
VERTICAL LATHE
|
|
SCHIESS-FRORIEP |
DYE-CNC |
|
Ø Max |
12.000 mm |
4.000 mm |
|
Maximum height |
6.500 mm |
2.450 mm |
|
Maximum weight |
125 Tn |
30 Tn |
MILLING/BORING MACHINE
|
|
INNSE |
SKODA |
FORIEP |
TOS |
|
Longitudinal Travel |
12.000 mm |
15.200 mm |
14.000 mm |
4.000 mm |
|
Weight on table |
100 Tn |
60 Tn |
60 Tn |
20 Tn |
|
Height travel |
5.250 mm |
4.200 mm |
5.000 mm |
3.000 mm |
|
Ø Max |
8.700 mm |
– |
– |
– |
PRESS
|
Presure |
400 Tn |
|
Max. width |
2.520 mm |
|
Max. height |
3.540 mm |
SURFACE TREATMENT SHOT-BLASTING AND PAINTING
| CABIN 1 | CABIN 2 | |
|
Max dimensions (width x height x length) |
8.000 x 6.000 x 14.000 mm | 6.000 x 5.000 x 14.000 mm |
MAXIMUM LIFTING CAPACITY
| Workshop 4 | Workshop 3 | Workshop 2 | Workshop 1 |
| 200 Tn | 160 Tn | 30 Tn | 30 Tn |
ADDITIONAL SERVICES
|
Welding procedures |
YES | |
|
NDT-UT |
YES | Outsourced |
|
NDT-X-ray |
Outsourced | |
| Production plan | YES | |
| Leak test | YES | |
| Load test | YES | |
| Shears | YES | |
| Bending machine | YES | |
| Band saw | YES |
MACHINERY
-
Vertical CNC machining up to 12 x 6,5 m and 125 Tn
-
CNC machining up to 12 x 5,5 m and 120 Tn
-
MIG/MAG, SAW, SMAW and TIG welding
-
Heat treatment up to 8,1 x 3,8 x 14 m (width x height x length)
-
Shot-blasting and painting cabins up to 8 x 6 x 14 m (width x height x length)
-
NDT-UT. NDT-X-ray, Leak test and Load test
LOCATION
The location of Gometegui Industrial is very close to the Port of Bilbao accelerating the delivery times of the components.
Katuxa Ibarra 7
01400 - LAUDIO LLODIO (ARABA) SPAIN
+34 946 728 505
info@gome.adiweb.es
HEAVY INDUSTRY MANUFACTURING
Experts in the comprehensive manufacture of large components for heavy industry
Send us your inquiry
